MY SD Automatic Insulating Oil Acid Value Tester IP65 High Precision Transformer Oil Acidity Analyzer

Name: MY SD Automatic Insulating Oil Acid Value Tester IP65 High Precision Transformer Oil Acidity Analyzer
Brand: MINGYANG
Price: 2500 USD

China MY SD Automatic Insulating Oil Acid Value Tester IP65 High Precision Transformer Oil Acidity Analyzer wholesale

Price : 2500usd

Packaging Details : carton

Place of origin : Hubei, China

Allowable ground voltage : ≤5V,error≤±5%

Accuracy : ±1%

Model Number : MY SD

Power : Electronic

Huminity : ≤85% RH

Supply Ability : 1000pcs/month

Weight : ≤1.4kg

Application : Oil Acid Value Tester

Accuracy Class : Standard Accuracy

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Maximum power loss : ≤2W

Voltage : 220 V

Delivery Time : 1 week

Dimension : 220*200*105mm3

Type : Oil Acid Value Tester

Brand Name : MINGYANG

Warranty : 1 Years

Temperature : 10 ℃ ~ 45 ℃

Protection Class : IP55

Power supply : AC220V / 50Hz

Place of Origin : China Mainland

Customized support : OEM

MOQ : 1

The environment temperature : 0℃~+45℃

Resistance : 0~2Ω(10mA),2~20Ω(10mA),20~200Ω(1mA)

Contact Now

MY SD Automatic Insulating Oil Acid Value Tester IP65 High Precision Transformer Oil Acidity Analyzer

This advanced analysis machine features standard IP65 protection and is specifically designed for petroleum products testing. It provides precise measurement of acidic substances in insulation oil and other petroleum-based products.

Basic Info.

Model NO.

MY SD

The Minimum Resolution

0.0001 Mgkoh/G

Error Range-1

Acid Value 0.001~0.1000 Mgkoh/G: 0.02 Mgkoh/G

Error Range-2

Acid Value 0.1000~0.5000 Mgkoh/G:0.05 Mgkoh/G

Dimension

420*270*260 (mm)

Temperature

5~40

Relative Humidity

<85% Rh

Weight

About 9kg

Transport Package

Wooden Case or Carton

Specification

see details

Trademark

MINGYANG

Origin

China

Production Capacity

200 Sets Per Month

Product Overview

Petroleum products contain various acidic substances including inorganic acids, organic acids, esters, phenolic compounds, lactones, heavy metal salts, amine salts, and other compounds. These acidic components vary with the degree of oil refinement - less refined products typically contain higher concentrations. Organic acids can corrode metals, with smaller molecules being particularly corrosive to materials like lead and zinc, forming soaps that can aggregate into deposits affecting product storage and performance.

Key Features

Large blue LCD display with English menu interface
Logo-free button design for intuitive operation
Microcomputer-controlled automatic measurement and printing
Magnetic stirring system - quiet and reliable operation
Compact design with standard IP65 protection
Ideal for petroleum refineries, power plants, and research facilities

Technical Specifications

Test Capabilities	Essential instrument for oil analysis and quality inspection in refineries, power plants, and research units
Compliance Standards	GB/T 264 "Determination of Acid Value of Petroleum Products", GB7599, and GB7299 requirements
Operating Principle	Titration and neutralization method with microcomputer-controlled automatic liquid injection, titration, stirring, and endpoint determination

Technique parameters

Display	High definition color touch screen
Accuracy	0.01mgKOH/g between 0.001 and 0.1
	0.03mgKOH/g between 0.1~0.5
	0.07mgKOH/g between 0.5 and 1.0
	0.10mgKOH/g between 1.0 and 2.0
Resolution	0.0001 mgKOH/g
Measuring range	0.0001~10.000 mgKOH/g
Detection	Neutralization method
Number of samples	three
Supply voltage	AC220V ±10% 50HZ
Operating ambient temperature	5 ºC~50ºC
Operating environment humidity	≤75%
External dimensions	L×B×H 440×280×200mm
Printing	Thermal printing (40 line characters)
Power	60W
Weight	10kg

Product Images

MY SD Automatic Insulating Oil Acid Value Tester IP65 High Precision Transformer Oil Acidity Analyzer
