0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration

Wuhan Mingyang Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration

Delivery Time : 1 week

Impedance voltage% : >8

Rating input of converter : 220V 13.6A

Model Number : MY-DDG

Warranty : 2 Years

Price : 1600usd

Packaging Details : carton

Protection Class : IP55

Working Environment : 0-50℃, ≤85%RH

Supply Ability : 1000pcs/month

Accuracy : 0.1

Payment Terms : L/C,D/A,D/P,T/T,Western Union

Customized support : OEM, ODM, OBM, Software Reengineering

Place of Origin : China Mainland

Voltage : 220V Electrical Equipment

Brand Name : MINGYANG

Type : Testing Machine

MOQ : 1

Application : Auto Testing

Weight : 45kg

Contact Now

0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration
This primary current injection test system is designed for high current applications in power systems, laboratories, and various departments. As a short-term or intermittent work device, it features compact size, lightweight construction, excellent performance, and easy operation and maintenance. This essential electrical debugging equipment generates high current and is widely used in power plants, power distribution stations, electrical factories, research facilities, and laboratories.
System Overview
This versatile test system serves power plants, power distribution stations, electrical factories, research institutions, and laboratory environments. Designed for short-term or intermittent operation, it combines compact dimensions with lightweight construction while delivering reliable performance and straightforward operation and maintenance procedures.

Basic Info.

Model NO.
MY-DDG
Capacity
3-60kVA
Secondary V2
6
Secondary A2
500-10000
Weight
45-200kg
Structure Style
Integrated(<4000) Split(>4000)
Type
MY-Ddg
Power Source
AC220V
Power Supply
AC: 220V± 10%· 25A, 50Hz/60Hz
Resolution
0.1A
Accuracy
± 0.5%
Certificate
Ce/ISO
Colour
White
Transport Package
Wooden Case or Carton
Specification
see details
Trademark
MINGYANG
Origin
Hubei,China
HS Code
9031200090
Production Capacity
200 Sets Per Month
Key Features
  • Dual ammeters for monitoring different measurement ranges
  • Freely adjustable auto transformer for precise current control
  • Integrated indicator lighting and buttons for simplified operation
  • Modular incorporated and dividable structure for easy transportation
0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration
0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration
0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration
Dxplaination of the structure of the high-current generator: 1. Activation. 2. Power signal indicator. 3. Current meter. 4. Voltage meter. 5. Boost signal. 6. Stop button. 7. Voltage input terminal. 8. Grounding terminal.
0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration
Product Parameters
The equipment capacity is designed based on 5-minute short-term work system. For intermittent work, working time should be less than 2.5 minutes, before continuing to work it should be shut down for 10 minutes so that all parts of the machine can cool down. Specifications and technical parameters as follows:
Model Capacity (KVA) Primary Secondary dimensions (mm) Weight
( kg)
Structure Style
V1 A1 V2 A2
MY-500 3 220 15 6 500 430×338×550 45 Integrated
MY-1000 6 220 27 6 1000 500×380×600 65 Integrated
MY- 2000 12 380 31.6 6 2000 580×400×750 105 Integrated
MY- 2500 15 380 39.5 6 2500 600×430×790 145 Integrated
MY- 4000 24 380 63 6 4000 640×450×820 180 Integrated/ split
MY- 5000 30 380 79 6 5000 600×430×900
300×500×500
145
135
Split
MY- 6000 36 380 95 6 6000 600×430×900
300×500×500
150
140
Split
MY- 8000 48 380 126 6 8000 600×450×950
350×550×550
180 Split
MY- 10000 60 380 158 6 10000 800×600×1100
380×550×600
200 Split

Company Profile

Wuhan Mingyang Industrial Technology Co., Ltd. has a professional sales and technical team to deliver premium pre-sales consultation and full technical support.
We maintain an efficient after-sales team to timely resolve all product and technical issues for global customers.
Founded in 2008 and based in Wuhan, China, we are a high-tech enterprise specialized in R&D, production, sales, OEM/ODM customization and after-sales service of power testing and high-voltage inspection equipment.
We keep enhancing independent innovation, upgrading factory facilities and adopting digital management systems. With reliable quality and good reputation, we have built worldwide customer networks and gained global trust. We sincerely look forward to long-term cooperation with you for mutual development.
0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration
0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration
Pre-sales Consulting Service
We provide comprehensive and professional pre-sales consulting services. Dedicated sales staff and senior technical engineers are arranged to answer customers’ questions regarding products, technologies and cooperation on a one-on-one basis. We deliver complete and detailed product information throughout the whole process to help customers fully understand product parameters, performances and usage details. All products are reasonably priced with high cost performance to ensure customers get value for money. All quotations are officially verified and stamped by the management team with authenticity and compliance guaranteed. Customers are warmly welcomed to visit our factory for field inspection and business negotiation.
Contract Performance Service
A formal sales contract and supporting technical agreement will be signed by both parties upon confirmation of cooperation intention. Adhering to the principle of integrity, we strictly comply with all clauses of signed contracts and technical agreements to ensure smooth and efficient project implementation. We maintain efficient communication throughout the cooperation, actively follow up with customer demands, and record customers’ inquiries and project schedules in detail to provide continuous professional technical docking and support. In all links including delivery, installation, commissioning and operation training, we respond to customer needs promptly and deliver high-quality services with efficiency and professionalism.
Packaging & Delivery Lead Time
We will arrange product delivery within 5-20 working days after receiving the confirmation of customer payment. All products are professionally packed with high-strength sturdy cartons or wooden boxes. The durable packaging effectively prevents collision and damage during transportation, ensuring the safe arrival of all goods at the destination.
0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration
Shipping & Transportation Solutions
We offer diversified logistics solutions including express air freight, sea freight and railway transportation. We can recommend the most cost-effective and suitable shipping solution according to customers’ delivery time, budget and destination requirements. If customers appoint their own forwarders, we will fully cooperate and provide a complete set of official customs clearance documents to ensure smooth customs clearance. After shipment, we will continuously track the logistics progress until the goods are successfully and intactly received by customers
0.1 Class Accuracy High Current Primary Injection Tester for Relay and Circuit Breaker Calibration
Warranty & After-sales Service
We take 100% customer satisfaction as our core service goal. Customers may feedback any product problems at any time, and we will follow up and resolve issues properly in a timely manner. All products are covered by one-year free warranty and lifelong free technical support. We promise to provide exclusive professional solutions within 24 hours upon receipt of customers’ product fault and usage feedback to efficiently solve after-sales problems.
FAQ
1.Are you factory or trading company?
We are a professional manufacturer based in Wuhan, Hubei Province.
2.What is the MOQ?
Please contact our sales team for detailed MOQ.
3.Production & Delivery Time
Standard products: 3-5 working days delivery.
4.Custom orders: around 20 days, subject to quantity and specifications.
5.Payment Terms:50% T/T deposit in advance, 50% balance before shipment.
6.Can I customize products?
Yes, we support full customization according to your technical requirements.
